General Parameters
-
Capacity (Ton):4 Ton
-
Refrigerant:R22
-
Color:White
Capacity
-
Cooling Capacity KW:14
-
Cooling Capacity (BTU):48000
-
Heating Capacity (BTU):-
-
Air Circulation (m3/h):1750
-
Rated Power input (KW) Cooling:5.37
-
Rated Power Input (KW) Heating:-
-
Power Supply (Ph/V/Hz):3/380-415/50
-
EER/COP(W/W):2.61
Piping Connection
-
Gas Side Dia (mm):Gas Side Dia (mm)
-
Liquid Side Dia (mm):Liquid Side Dia (mm)
-
Max Pipe Length (m):Max Pipe Length (m)
-
Max Drop (m):"Max Drop (m)"
Warranty
-
Warranty:1 year Parts, 5 Years compressor
Dimensions
-
Indoor Net Dimension W/D/H:530/380/1820
-
Indoor Packing Dimension W/D/H:625/465/1965
-
Outdoor Net Dimension W/D/H:1008/410/830
-
Outdoor Packing Dimension W/D/H:1130/490/930
-
Panel Net Dimension W/D/H:-
-
Panel Packing Dimension W/D/H:-
Weight
-
Indoor Gross weight (Kg):62
-
Indoor Net weight (Kg):53
-
Outdoor Gross Weight (Kg):101
-
Outdoor Net Weight (Kg):91
-
Panel Gross Weignt (Kg):-
-
Panel Net Weignt (Kg):-
Noise
-
Indoor Noise [db(A)] (Hi/Mid/Lo):49/46/42
-
Outdoor Noise [db(A)]:62
